Brass Push-On (Push-Fit) Fittings – Technical Specifications
| Parameter | Details |
| Product Name | Brass Push-On / Push-Fit Fittings (Pneumatic & Fluid Connectors) |
| Types | Straight Union, Elbow 90°, Tee, Y-Connector, Bulkhead, Male Connector, Female Connector, Reducer, Plug |
| Materials Used | CW614N, CW617N Forging Brass, Nickel Plated Brass, Lead Free Brass (optional) |
| Sealing Components | NBR O-Ring (standard), FKM/Viton (optional), Stainless Steel Gripping Collet |
| Manufacturing Process | Hot Forged / CNC Machined / Precision Assembled |
| Tube Sizes | 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm OD (inch sizes available) |
| Threads | BSP, BSPT, NPT, Metric |
| Pressure Rating | Up to 10–16 bar (depending on tube & size) |
| Temperature Range | -20°C to +80°C (NBR) | up to +120°C (FKM optional) |
| Grades | Pneumatic Grade / Industrial Grade |
| Standards | ISO 14743, ISO 4414, DIN / BS as applicable |
| Tolerance | As per ISO / DIN or drawing |
| Surface Finish / Plating | Natural Brass, Nickel Plated (standard), Chrome optional |
| Corrosion Resistance | Good corrosion resistance for air, water & light oil applications |
| Applications | Pneumatic systems, air compressors, automation lines, packaging machines, robotics |
| Quality & Inspection | Leak testing, pull-out test, dimensional inspection |
| Compliance | RoHS, REACH available on request |
| Packaging | Standard export packing, polybag + carton & customized |
| MOQ | Flexible depending on size & type |
| Customization | Fully customizable as per drawing/sample – thread type, tube size, sealing material, plating & packaging |
