Brass Flare Fittings – Technical Specifications
| Parameter | Details |
| Product Name | Brass Flare Fittings (SAE 45° / JIC 37°) |
| Types | Male Connector, Female Connector, Elbow 45°/90°, Tee, Union, Reducer, Bulkhead, Cap & Plug |
| Materials Used | CW614N, CW617N Forging Brass, Lead Free Brass, DZR Brass (optional) |
| Sealing Method | Metal-to-Metal Flare Seat (Single Flare / Double Flare) |
| Manufacturing Process | Hot Forged / CNC Machined / Precision Turned |
| Tube Sizes | 1/8″–1″ OD Tube (Metric sizes available) |
| Threads | UNF, SAE, BSP, NPT |
| Pressure Rating | Up to 3000 PSI depending on size & tube material |
| Temperature Range | -40°C to +150°C |
| Grades | Hydraulic Grade / Refrigeration Grade |
| Standards | SAE J512, SAE J513, ISO 8434-2, DIN 3861 |
| Tolerance | As per ISO / SAE or drawing |
| Surface Finish / Plating | Natural Brass, Nickel Plated, Chrome Plated |
| Corrosion Resistance | High corrosion resistance for fuel, gas & refrigeration lines |
| Applications | HVAC, refrigeration systems, fuel lines, hydraulic systems, gas distribution |
| Quality & Inspection | Seat angle inspection, leak testing, dimensional & thread gauge inspection |
| Compliance | RoHS, REACH available on request |
| Packaging | Export standard packing, polybag + carton, customized packing |
| MOQ | Flexible depending on size & type |
| Customization | Fully customizable as per drawing/sample – flare angle, thread type, material grade, plating & packaging |
